MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010 179
Read Status Operating Instructions
Central Station Screen #2 provides information on the Primary and Secondary Central Station
programming which includes:
• Test Time Interval
• Account Code
• 24 Hour Test Time
• Phone Number
• Communication Format
• Event Codes
4.22.13 Service Terminal
Pressing 1 while viewing Read Status Screen #5 will display the following screens:
The Panel ID number is displayed as the first item in Service Terminal Screen #1.
To view the phone number for each Service Terminal, press 2 for Terminal 1 or 3 for Terminal 2
while viewing Service Terminal Screen #1.
The Ring Count is displayed in Service Terminal Screen #2.
4.22.14 Printer/PC
Pressing 2 while viewing Read Status Screen #5 will display the following screen:
The display will inform the operator as to whether the control panel is configured for a printer or a
PC. In the example above, PR4800 indicates that the panel is configured for a printer with a baud
rate of 4,800.
READ STATUS
1=SERVICE TERMINAL
2=PRINTER/PC
3=PRINT
Read Status Screen #5
SERVICE TERMINAL
RING COUNT
Service Terminal Screen
PRINTER PC
PRINTER PC PR4800
Printer/PC Screen
