142 MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010
Programming Master Programming Level
Ademco Contact ID & SIA Formats
The information shown in Table 3.11 is automatically programmed for the Central Station phone
number Event Codes when the Ademco Contact ID or SIA Format is selected. Enter 0s for an
Event Code Setting to disable the report. Disabled reports will not get called to the Central Station.
The programmer may enable the Event Types in programming as described on the previous page.
Event Description Ademco Contact ID SIA
Active Zone Point Active Restoral
PULL STATION 115 Zone Point FA FH
MON-USER-DEF-1 115 Zone Point FA FH
WATERFLOW 113 Zone Point SA SH
MON-USER-DEF-2 113 Zone Point SA SH
SMOKE (PHOTO) 111 Zone Point FA FH
DET-USER-DEF-1 111 Zone Point FA FH
SMOKE (ION) 111 Zone Point FA FH
DET-USER-DEF-2 111 Zone Point FA FH
HEAT DETECT 114 Zone Point KA KH
DET-USER-DEF-3 114 Zone Point KA KH
SMOKE DUCT-P 116 Zone Point FA FH
DET-USER-DEF-4 116 Zone Point FA FH
PHOTO W/HEAT 111 Zone Point FA FH
DET-USER-DEF-5 111 Zone Point FA FH
DUCT SUPERVISORY 200 Zone Point FS FV
DET-USER-DEF-6 200 Zone Point FS FV
PHOTO SUPERV 200 Zone Point FS FV
DET-USER-DEF-7 200 Zone Point FS FV
PHOTO ADAPT 111 Zone Point FA FH
DET-USER-DEF-8 111 Zone Point FA FH
PHOTO BEAM 111 Zone Point FA FH
DET-USER-DEF-9 111 Zone Point FA FH
MONITOR 110 Zone Point FA FH
MON-USER-DEF-3 110 Zone Point FA FH
SMOKE CONVEN 111 Zone Point FA FH
MON-USER-DEF-5 111 Zone Point FA FH
HEAT CONVENTIONAL 114 Zone Point KA KH
MON-USER-DEF-6 114 Zone Point KA KH
MEDIC ALERT 100 Zone Point MA MH
MON-USER-DEF-7 100 Zone Point MA MH
HAZARD ALERT 150 Zone Point PA PH
MON-USER-DEF-8 150 Zone Point PA PH
TORNADO ALRT 150 Zone Point PA PH
MON-USER-DEF-9 150 Zone Point PA PH
MON-PHONE 000 00 00
MON-USER-DEF-10 000 00 00
TAMPER 144 Zone Point TA TH
MON-USER-DEF-11 144 Zone Point TA TH
MON SUPERVISORY 200 Zone Point FS FV
MON-USER-DEF-12 200 Zone Point FS FV
MON SUPERV AUTO 200 Zone Point FS FV
MON-USER-DEF-13 200 Zone Point FS FV
HVAC OVRRIDE 200 Zone Point FS FV
POWER MON 330 Zone Point AT AR
MON-USER-DEF-14 330 Zone Point AT AR
TROUBLE MON POINT_FAULT code will always be transmitted
MON-USER-DEF-15 POINT_FAULT code will always be transmitted
PROCESS MON 000 00 00
MON-USER-DEF-16 000 00 00
PROCMON AR 000 00 00
MON-USER-DEF-17 000 00 00
Table 3.11 Event Codes
