MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010 141
Master Programming Level Programming
Event Codes
Pressing 1 while viewing Primary/Secondary Screen #4 will cause the following screen to be
displayed:
Pressing the down arrow key allows viewing of all Events associated with the selected
Communication Format. Pressing the number corresponding to the event displayed in each screen
will display its default event code which can be customized by the programmer. For example,
pressing 1 for Pull Station will display the following screen which allows the Event Code to be
changed from the default value.
The tables on the following pages list all of the Events and their default Event Codes for the various
Communication Formats.
CENTRAL STATION
1=EVENT CODES
Primary/Secondary Screen #4
EVENT CODES
1=PULL STATION
2=MON-USER-DEF-1
3=WATERFLOW
Event Code Screen
PULL STATION
ALARM 000
Event Code Screen
To Next Page
