Operating Instructions Read Status
4.22.15 Print
To print program data or control panel status, press 3 while viewing Read Status Screen #5. The
following screens will be displayed:
Pressing 1 while viewing Print Screen #1 allows the user to print the History file which will detail
all of the system activities since the file was last cleared from memory.
Pressing 2 while viewing Print Screen #1 allows the user to print the Walktest log which will detail
all of the system activations during walktest since the log was last cleared. Refer to “Walktest” on
page 114 for additional information on the display.
Pressing 3 while viewing Print Screen #1 allows the user to print the detector data for each
addressable smoke detector connected to the system. A printout, similar to the following example,
will be generated if an optional printer is connected to the FACP.
Chamber Value
The Chamber value should be within the indicated range for the following smoke detectors:
• SD355, SD350(T) D350P(R) and SD300(T) Addressable Photoelectric Smoke Detectors: 405
- 2100 (obscuration of 1.00%/ft to 3.66%/ft.)
• CP355, CP350, and CP300 Addressable Ionization Smoke Detectors: 750 - 2100 (obscuration
of 0.50%/ft. to 1.44%/ft.)
READ STATUS
1=FUTURE USE
2=PRINTER/PC
3=PRINT
Read Status Screen #5
PRINT
1=HISTORY
2=WALKTEST LOG
3=DETECTOR DATA
PRINT
1=EXIT PRINTING
Print Screen #2
Print Screen #1
DEVICE # DEVICE TYPE % DRIFT COMP CHAMBER TIME/DATE
1D001 SMOKE (PHOTO) 20 1281 12:01 AM 01-08-2001
1D002 SMOKE (PHOTO) 20 1281 12:01 AM 01-08-2001
1D003 SMOKE (PHOTO) 21 1259 12:01 AM 01-08-2001
1D004 SMOKE (PHOTO) 20 1309 12:02 AM 01-08-2001
1D005 SMOKE (PHOTO) 21 1281 12:02 AM 01-08-2001
1D006 SMOKE (PHOTO) 20 1322 12:02 AM 01-08-2001
1D007 SMOKE (PHOTO) 20 1280 12:02 AM 01-08-2001
1D008 SMOKE (PHOTO) 20 1215 12:02 AM 01-08-2001
1D009 SMOKE (PHOTO) 20 1310 12:02 AM 01-08-2001
