MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010 125
Master Programming Level Programming

ANN-LED Options
Pressing 2 for Module Options while viewing the ANN-BUS Address Screen when the ANN-LED
option is selected, will display the following screen:
The first screen indicates that the ANN-LED at the selected ANN-BUS address is programmed to
annunciate Alarms, Supervisories, and Troubles for SLC Loop #1 addressable Detectors with
addresses 1 through 10. The programming can be changed using ANN-LED Address Screens 2
and 3.
Pressing 1 while viewing ANN-LED Address Screen #2 will program the annunciator module to
annunciate either Point (addressable device address) information or Zone information.
Pressing 2 while viewing ANN-LED Address Screen #2 will program the annunciator module to
annunciate only Alarms for addressable device addresses 1-30 or Alarms, Supervisories, and
Troubles for addressable device addresses 1-10.
Pressing 1 while viewing ANN-LED Address Screen #3 will select the Point or Zone range to be
annunciated - refer to the tables in “ANN-LED Zone Option - Alarm Only (for use with ANN-
RLED module)” on page 126 and “ANN-LED Point Option - Alarm Only (for use with ANN-
RLED module)” on page 128.
Pressing 2 while viewing ANN-LED Address Screen #3 will select either addressable detectors or
addressable modules to be annunciated.
PRIMARY ANN-BUS
1=ENABLED YES
2=MODULES INSTALLED
3=AUTO-CONFIGURE
ANN-BUS Screen #2
ANN-LED - ADDR X-1
SLC 1 DET 1-10
ALARM, TBL, SUPV
ANN-LED Address Screen #1
ANN-LED - ADDR X-1
1=POINT/ZONE
2=ALARM/ATS
ANN-LED Address Screen #2
ANN-LED - ADDR X-1
1=RANGE
2=DET/MOD
ANN-LED Address Screen #3
