MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010 221
Canadian Application
Figure I.2 FACP Maximum Configuration - Eight ANN-LEDs
ANN-LEDs
FACP
ANN-LED
ANN-80C
ANN-I/O
ANN-S/PG
ANN-RLY
9
2
0
0
u
l
s
c
-
a
n
n
l
e
d
8
.
w
m
f
Optional Secondary ANN-BUS (data on
connector TB8, power on TB1 Terminals
3&4 with JP6 pins 1&2 jumpered)
Primary ANN-BUS
(data on connector
TB9, power on TB1
Terminals 1&2)
in metal conduit
(adjacent to FACP)
