Seite/Page 16 - Kaptitel/Chapter 1: General Instructions and Regulations 16.1.15

1.2 Tools

These symbols are used throughout this manual to show which tool must be used for maintenance or installation.

Spanners

W.A.F X = width across flats of X mm

Hook wrench for oil filter

Screw driver, for slotted head screws and for Phillips head screws

Multimeter, multimeter with capacitor measuring unit

Socket wrench set

Hexagon socket wrench set
