Installation Instructions
16.1.15 Kapitel/Chapter 5: Installation Instructions - Seite/Page 61
Fig. 5.5.1-4: Pre filter with water separatorPre filter with water separator
Alternative Article
representative picture
Fig. 5.5.1-5: Quick connector for fuel linesQuick connector for fuel lines
representative picture
Fig. 5.5.1-6: Hose clampsHose clamps
representative picture
5.5.1.1 The following items need to be installed:
• Fuel supply pump (DC)
• Pre-filter with water separator (not part of the delivery)
• Fine particle fuel filter
• Return fuel line to fuel tank (unpressurized)
The external Fuel pump should be installed near the tank
