General operation
16.1.15 Kapitel/Chapter 11: General operation - Seite/Page 181
11.4 Other operating functions
11.4.1 Set-up menu
In the set-up menu, a series of parameters can be modified directly using the control panel. To access the set-up
menu, you have to actuate the cursor-down button immediately after switching on the controller with the On/Off
button and while the start screen with panda bear is still being displayed. This will open a menu with the following
sub-items:
Fig. 11.4.1-1: Set-up menu
Fig. 11.4-2: Set-up menu
With the cursor-up and cursor-down buttons, you can
navigate through the menu. The currently selected menu
item is marked with two asterisks (*), e.g. "backlight 2":
Set-up menu with item highlighted: *backlight 2*
Note:The Start/Stop button is used for confirming a selection
in the set-up menu. If you confirm the row marked with
the * with the Start/Stop button, you will access the
selected sub-menu.
Fig. 11.4-3: Set-up menuSet-up menu
Menu item Settings range for
backlight 1 Setting the brightness value for the standard backlighting to 0-9
backlight 2 Setting the brightness value for the dimmed backlighting to 0-9
Dimtime (dimming time) Time until the display switches to dimmed mode, 0-225s, 0= function deactivated
Config Password protected area for Fischer Panda associates and Fischer Panda service points
Network ID Settings for the network ID of the panel
Save & Exit Saving the values and exiting the set-up menu
Autostart Activating and deactivating the automatic start-up function
Service Resetting the "Operating hours to service" indication
Prime fuel Activation of the fuel pump to prime the generator fuel system
Degree C/F Switches the display between °C and °F
