Installation Instructions

16.1.15 Kapitel/Chapter 5: Installation Instructions - Seite/Page 59

Fig. 5.4.0-2: Connections - sample

5.5 Fuel system installation

5.5.1 Fischer Panda installation kit - Fuel system

Note:The following additional components will be required for

the specified installation. You can purchase them as an

installation kit or separately at Fischer Panda.

1 2 3

1. Connection cooling water IN

2. Connection cooling water OUT

3. Connection exhaust OUT

4. Connection to external expansion tank
