Installation Instructions
16.1.15 Kapitel/Chapter 5: Installation Instructions - Seite/Page 95
5.16 Technical Data
Characteristics
closed current (electronics off) 0,5mA
closed current (electronics on) 10 - 15mA
Benchmark figure of the temperature control:
fan start-up 60°C - 80°C
max. number of revolution 65°C - 100°C
tolerance of the temperatures ± 5%
Maximum ratings
maximum ambient temperature (for operation) 50°C
Maximum ratings: Battery operation 12V
nominal load operating voltage (continuity) 11 VDC - 14.4 VDC
load operating voltage (15min) - 16.0 VDC
maximum idle speed operating voltage (3 sec) 17 VDC
nominal load current (continuity) 40 A
maximum load current (3 sec) 44 A
nominal voltage fan 12 VDC
Maximum ratings: Battery operation 24V
nominal load operating voltage (continuity) 18 VDC - 28.0 VDC
load operating voltage (15min) - 28.8 VDC
maximum load operating voltage (3 sec) 30 VDC
idle speed voltage (continuity) 34 VDC
maximum idle speed operating voltage (3 sec) 36 A
nominal load current (continuity) 20 A
maximum load current (3 sec) 22 A
nominal voltage fan 24 VDC
Maximum ratings: Transformer operation 12V
sieving in the power supply 10000µF 63V (depending on the load current)
data for secondary winding after rectification/sieving
nominal load operating voltage (continuity) 11 VDC - 14.4 VDC
load operating voltage (15min) - 16.0 VDC
maximum load operating voltage (3 sec) 17 VDC
idle speed operating voltage (continuity) 28 VDC
maximum idle speed operating voltage (3 sec) 30 VDC
nominal load current (continuity) 40 A
maximum load current (3 sec) 44 A
nominal voltage fan 12 VDC
Maximum ratings: Transformer operation 24V
sieving in the power supply 10000µF 63V (depending on the load current)
data for secondary winding after rectification/sieving
full load operating voltage (15min) 18 VDC - 28.0 VDC
load operating voltage (15min) - 28.8 VDC
maximum full load operating voltage (3 sec) 30.0 VDC
maximum partial load operating voltage 36.0 VDC
idle speed operating voltage (continuity) 39.0 VDC
maximum idle speed operating voltage (3 sec) 40.0 VDC
maximum input peak voltage 44.0 VDC *1)
maximum output peak voltage 44.0 VDC *1)
nominal load current (continuity) 24 A
