Installation Instructions

Seite/Page 88 - Kaptitel/Chapter 5: Installation Instructions 16.1.15

5.11.2 Installation for mounting the radiator under the vehicle

Fig. 5.11.2-1: Underfloor radiator - schematic

01. Ventilation line

02. Coolant expansion tank

03. T-fitting with connection for thermal switch

04. T-fitting

05. Radiator

06. Fan for radiator
