Installation Instructions

Seite/Page 90 - Kaptitel/Chapter 5: Installation Instructions 16.1.15

5.12 Radiator fan control / electronic fan control

To control the radiator fan, various controls/electronic controls can be chosen from the Fischer Panda delivery

program.

Note!:In the following the basic functions of the fan controls

are described. The original manual/ data sheet with

further informations of the fan control must be

respected.

5.13 Standard fan control for 1-phase and 3-phase generators.

In the standard kit, the generators will be equipped with a one step fan control.

Fig. 5.13.0-1: Fan control 230VFan control 230 V

representative picture
