DC100 MAX Digital Dispenser Operating Manual
© 2023 Fisnar - 25 - DC100 MAX Rev 4
The button can continue to be pressed to cycle through the digit and
decimal place positions in a continuous scrolling cycle.
When the dispense time has been correctly set, press and hold the
button for approximately two (2) seconds to save the dispense time and exit
back to the home screen.
3.
Press the foot pedal or the button to actuate the machine and begin
dispensing fluid.
The dispense time will automatically start counting downwards from the set
dispense time until it reaches zero (0) seconds.
When the dispense time reaches zero (0) seconds, the machine will
automatically stop dispensing and the dispense time will reset back to the
set dispense time.
The machine will then automatically start counting down from the time set in
the “Cycle Delay” function setting until it reaches zero (0) seconds.
Once the machine has counted down to zero (0) seconds, it will
automatically begin dispensing fluid again according to the set dispense
time until it reaches zero (0) seconds.
The dispense cycle can be stopped before the dispense time reaches zero
(0) by pressing the button.
This looping cycle will continue to be repeated until the or button
is pressed again.
A full shot cycle is counted towards the cumulative dispense counter
whenever the dispense timer reaches zero (0).
