DC100 MAX Digital Dispenser Operating Manual

DISPLAY SCREEN

1. Program Number

Displays the currently selected program number. Up to sixteen (16)

individual programs can be saved to the machine for future recall.

2. Dispense Mode

Displays the current mode the saving program is in. There are five (5)

dispense modes available: PURGE, TEACH, TIMED,

TIME+ and

CYCLE.

3. Function Alarms

Displays which feature(s) are currently turned ON. I.E. Dispense Limit

(L), Glue Alarm (G), Pressure Alarm (P), Vacuum Alarm (V) and Auto

Purge (A).

4. Parameter Values

Displays the values of the machine parameters (i.e. dispensing time,

pressure and/or vacuum).
