FISNAR DC100 MAX - Pressure Alarm

DC100 MAX Digital Dispenser Operating Manual
© 2023 Fisnar - 31 - DC100 MAX Rev 4
FUNCTION MENU
3. Pressure Alarm
This function allows the user to set a pressure value threshold (as well as a corresponding percentage
tolerance) that must be met in order for the machine to be actuated. A visual and audible alarm will trigger
if the set regulated pressure is not within tolerance.
1.
When the Pressure Alarm page is displayed, press the button to enter into the setting page
for the Pressure Alarm.
2.
There are two (3) adjustable parameters for this function: MODE, Pressure, Tolerance. Press the
button to scroll through these parameters.
3.
MODE: Use the or buttons to turn the Pressure Alarm MODE On or Off.
4.
Pressure: Use the or buttons to set the required regulated Pressure value.
Or, press the button
to import the set regulated pressure value, displayed on the home
screen.
