DC100 MAX Digital Dispenser Operating Manual
© 2023 Fisnar - 26 - DC100 MAX Rev 4
FUNCTION MENU
The machine offers built-in functions that provide additional control and adjustment
application and machine settings.
Instructions:
• Press the button to enter the Function menu.
• Press the buttons to scroll through the available function settings.
• Press the button to enter into the selected function setting and adjust/set as needed.
• Press the button to exit the function menu.
Overview:
1. Program Number Sets the program number that the machine will operate in.
2. Glue Alarm
Sets the amount of time that the machine will operate for, before an
alarm signal is automatically activated preventing the machine from
being actuated.
3. Pressure Alarm
Sets the pressure and tolerance required for optimum dispensing
conditions.
4. Vacuum Alarm
Sets the vacuum and tolerance required for optimum dispensing
conditions.
5. Auto purge
Sets the dispense time and delay time for automatic purging of
material.
6. Add Time+
Sets the amount of time added to the TIME+ value when the “Set”
button is pressed.
7. Cycle Delay
Sets the amount of time that the machine will remain idle for after
executing a dispense cycle, before automatically actuating the next
dispense cycle, when the machine is in “CYCLE” mode.
