DC100 MAX Digital Dispenser Operating Manual
© 2023 Fisnar - 18 - DC100 MAX Rev 4
DISPENSE MODES
PURGE MODE
1.
Press the button untilPURGE mode is displayed.
PURGE mode allows the operator to actuate the machine on demand whenever
the dispense signal is activated (i.e. foot pedal is pressed).
2.
Press the foot pedal or the button to actuate the machine
and begin
dispensing fluid. Release the foot pedal or button to stop dispensing fluid.
The machine will count up from zero (0) seconds
the amount of time you are
dispensing fluid while the foot pedal or button is pressed.
The TIME shown on the digital display after the foot pedal or button has
been released, will reset to zero (0) seconds every time the machine is actuated.
