FUNCTION MENU
12. Shot Actuation
This function allows the user to set if the dispense actuation signal will work as a momentary or latching
type when the machine is set to PURGE mode.
Momentary (Default) = The machine will actuate for as long as the dispense actuation signal is received.
When the dispense actuation signal is not received the machine will stop actuating.
Latching = The machine will actuate for as long as the dispense actuation signal is received. When the
dispense actuation signal is not received the machine will continue to actuate. When the next dispense
actuation signal is received the machine will stop actuating.
1.
When the Shot Actuation page is displayed, press the button to enter into the setting page
for the Shot Actuation.
2.
Use the or buttons to set the shot actuation type,
3.
Press the button to exit the selected function setting.
