FISNAR DC100 MAX - Page 46

DC100 MAX Digital Dispenser Operating Manual
© 2023 Fisnar - 46 - DC100 MAX Rev 4
10.
When the sequence has executed through to the completion of the program number selected in
the End parameter, a pop-up message “!Sequence End!” will be displayed on the screen.
It will not be possible to actuate the machine further until it has been reset.
11.
The Sequence is reset back to the program number selected in the Start parameter by pressing
the button or momentarily (two (2) seconds) activating pin #16 of the I/O input circuit.
If the machine is reset whilst in the middle of carrying out a sequence, it will reset back to the
program number selected in the Start parameter
