DC100 MAX Digital Dispenser Operating Manual

DISPENSE MODES

CYCLE MODE

Press the button until “CYCLE” mode is displayed.

CYCLE mode allows the operator to create a repeating cycle of dispense

actuations. For example, dispense for 1 second and then wait for 3 seconds,

and cycle these times over and over again.

Press the button to set the dispense time. Use the buttons

to change the individual numeric value. The digit displaying the “_” below it,

is the one that will be adjusted.

Continue to press the

button to scroll through the digit positions,

adjusting the numerical values as required.

When the button is pressed after the first digit from the left is displaying

“_” below it, the “_” will move to below the decimal place. Use the

buttons to move the decimal place into the correct needed position.
