DC100 MAX Digital Dispenser Operating Manual
© 2023 Fisnar - 12 - DC100 MAX Rev 4
1. Power On / Off
Press the button to switch the machine ON or OFF.
2. Function Menu
Press the button to enter into the function menu.
3. Dispense Mode
Press the button to select the dispense mode that the program
will operate in (i.e. PURGE, TEACH, TIMED, TIME+, CYCLE).
4.
Set Dispense Time
/ Function Menu
Navigate
Press the button to set the dispense time. Use the or
buttons to change the individual numeric value. The digit displaying
the “_” below it, is the one that will be adjusted.
Continue to press the button to scroll through the digit positions,
adjusting the numerical values as required.
When the button is pressed after the first digit from the left is
displaying “_” below it, the “_” will move to below the decimal place.
