DC100 MAX Digital Dispenser Operating Manual
© 2023 Fisnar - 32 - DC100 MAX Rev 4
5.
Tolerance: Use the or buttons to set the Tolerance. When this tolerance is exceeded
above or below the set pressure, then the Pressure Alarm will be activated.
6.
Press the button to exit the selected function setting.
7.
A letter “P” will be displayed on the home screen when this function is turned ON.
8.
Whenever the regulated pressure is outside of the set tolerance, the letter “P” will flash and it will
not be possible to actuate the machine. Pin #6 of the I/O output circuit will also be activated.
If the machine is actuated when the Pressure Alarm is activated, a pop-up message “!Pressure
Alarm!” will be displayed on the screen and an audible noise heard.
9.
The pop-up message “!Pressure Alarm!” is removed by pressing the button or momentarily
(two (2) seconds) activating pin #16 of the I/O input circuit.
Check the MAIN AIR IN pressure and/or adjust the pressure regulator on the front of the machine
as needed.
