FLENDER FLUDEX - Technical Specifications; Filling Quantity; Filling Quantity for FLUDEX Couplings FN; Table A-1 Filling Quantity for FLUDEX Couplings FN

M4602-02en Edition 09/2022 73
Technical specifications
A
A.1 Filling quantity Filling quantity
A.1.1 Filling quantity for FLUDEX couplings FN.. Filling quantity
Guide values for mineral oil VG 22/Vg 32
For drive via blade shell (101) (outer wheel), valid for T
max.
= 1.3 x T
Nenn
Information
In case of deviating operating fluids or T
max.
≠ 1.3 x T
Nenn
, changed filling quantities must be
observed.
A.1.1.1 Filling quantity for FLUDEX couplings “FN..” Size 370 Filling quantity
Power
kW
Speed in rpm
600 740 890 980 1180 1470 1770 2300 2950 3550
Oil filling quantity in litres
1.1 5.6
2.2 7.1 5.7
3.0 7.9 6.4 5.1
4.0 8.2 7.0 5.8 5.1
5.5 7.8 6.5 5.9
7.5 8.2 7.2 6.5 5.3
11 8.2 7.4 6.2
15 8.2 6.8 5.4
18 7.2 5.8
22 7.8 6.2 4.9
30 6.9 5.7
37 7.4 6.1 4.4
45 7.9 6.6 4.7
55 7.0 5.3
75 7.8 6.0 4.3
90 6.4 4.6
110 6.8 5.1
132 7.2 5.6 4.3
