FLENDER FLUDEX - Filling Quantity for FLUDEX Couplings FN.. Size 425; Table A-2 Filling Quantity for FLUDEX Couplings FN

Technical specifications
Filling quantity
74 Edition 09/2022 M4602-02en
Power
kW
Speed in rpm
600 740 890 980 1180 1470 1770 2300 2950 3550
Oil filling quantity in litres
160 6.0 4.7
200 6.5 5.2
250 5.8
TableA-1: Filling quantity for FLUDEX couplings “FN..” Size 370
Information
Observe the maximum permissible oil filling quantity of 8.2 litres.
A.1.1.2 Filling quantity for FLUDEX couplings “FN..” Size 425 Filling quantity
Power
kW
Speed in rpm
600 740 890 980 1180 1470 1770 2300 2950
Oil filling quantity in litres
2.2 8.5
3.0 9.7
4.0 10.7 8.6
5.5 12.0 9.7
7.5 12.5 10.7 8.8 7.7
11 12.2 10.2 9.2
15 12.5 11.2 10.2 8.3
18 12.0 10.8 8.9
22 12.5 11.6 9.6
30 12.5 10.7 8.5
37 11.4 9.2 7.1
45 12.3 9.8 7.8
55 10.5 8.6
75 11.6 9.7 6.9
90 12.4 10.3 7.4
110 11.0 8.3
132 11.7 8.9 6.6
160 9.6 6.9
200 10.3 7.6
250 8.6
