Table 13. Description of parameters in the <CONFIG PORT> command.
Port Number of the voice port (P1…P8).
Type Type of installed daughter boards (2EM, FXS, FXO).
Signaling Signaling type (see the <SIGNALING> command)
State Port status:
LOCK – blocked;
UNLOCK – interface is not blocked;
OFF – port in the idle mode;
ON – port is active.
PB Passive Byte (free-channel constant)
RB Replace Byte (replacement constant)
PTS Number of the time slot onto which the voice port is cross-connected
STS Reserved
GainRX Receiver gain, dB (see the <PORT> command)
GainTX Transmitter gain, dB (see the <PORT> command)
LEC Line Echo Cancel, echo suppression (see the <PORT> command)
NRT Configured threshold of noise suppression (see the <PORT> command)
PLEX2_01_CM>CONFIG STREAM
Module PCM streams configuration:
----------------------------------------------------------------------------
Stream Type Medium SigTS LDL RDL SyncSource FTS Padding Led
----------------------------------------------------------------------------
PCM1 PCM30C TwPair 16 OFF OFF Internal FF *
PCM2 ---- ------ ----- --- --- ---------- ----------- -----------
PCM3 ---- ------ ----- --- --- ---------- ----------- -----------
----------------------------------------------------------------------------
Module V35 stream configuration:
----------------------------------------------------------------------------
V35Band Speed ClkMode ClkRX ClkTX DSR CTS DCD RTS DTR TEST
----------------------------------------------------------------------------
--------- --- CoDir Normal Inverse ON ON OFF ON ON OFF
----------------------------------------------------------------------------
Module Ethernet stream configuration:
----------------------------------------------------------------------------
EthType Duplex ModeDetect BridgeBand BridgeSpeed
----------------------------------------------------------------------------
10BASE-T Half manual control --------- ---------------------------
10BASE-T Half manual control --------- ---------------------------
----------------------------------------------------------------------------
PLEX2_01_CM>
