User’s manual FlexGain Plex, V2
Version 1.3 63 from 99
Table 14. Description of the parameters in the <CONFIG STREAM> command.
Stream Number of the Е1 stream (PCM1, PCM2, PCM3).
Type Operation mode of Е1 streams (see the <PCMMODE> command).
Medium Type of medium: TwPair is twisted pair.
SigTS Signaling time slot of CAS.
LDL Status of the local loop
ON – the loop is activated.
OFF – the loop is deactivated.
RDL Status of the remote loop
ON – the loop is activated.
OFF – the loop is deactivated.
SyncSource Clock source.
INTERNAL – internal clock source;
EXTERNAL – external clock source;
PCM1 – synchronization from the incoming E1 stream.
FTS Padding Padding of free TSs.
Led The asterisk shows to which stream the E1 LED on the front panel is assigned.
V35Band Shows the range of TSs of the Е1 stream, which are multiplexed on the V35
port (1.1 – 1.10 means that the data from the V35 interface are cross-
connected in time slots from 1 to 10 of the PCM1 stream).
Speed Operation speed of the V35 port. It is calculated as N*64kbps, where N is the
number of used time slots TS (10*64 = 640 kbps).
ClkMode Synchronization of the V35 port (see the V35CLKMODE command).
ClkRX Synchronization of the V35 receiver (see the V35CLKRX command).
ClkTX Synchronization of the V35 transmitter (see the V35CLKTX command).
DSR Status of the DSR line of the V35 port management.
CTS Status of the CTS line of the V35 port management.
DCD Status of the DCD line of the V35 port management.
RTS Status of the RTS line of the V35 port management.
DTR Status of the DTR line of the V35 port management.
TEST Status of the TST line of the V35 port.
EthType Type of Ethernet connection (10 Mbit, 100 Mbit).
Duplex Status of the duplex ETHERNET connection (FULL, HALF).
ModeDetect Status of the detection mode of the type of the ETHERNET connection.
manual control – manual.
