User’s manual FlexGain Plex, V2
Version 1.3 65 from 99
(Cross-connect of V.35 to slots from TS1 to TS19 of the PCM2 stream, excluding 16TS,
cross-connect of three voice ports to TS20, TS21, TS22 in the PCM2 stream)
PLEX2_01_CM>CONNECT V35 PCM2 1 19
Stream V35 by speed 1152 kbit/s (18 ts) allocated in space of the stream PCM2.
PLEX2_01_CM>CONNECT P1 PCM1 20
PLEX2_01_CM>CONNECT P2 PCM1 21
PLEX2_01_CM>CONNECT P3 PCM1 22
PLEX2_01_CM>CONNECT
FlexGain Plex2 cross-connect map:
------------------------------------------------------------------
PCM1 : PCM2 : PCM3
------------------------------------------------------------------
TS TARGET TS TARGET :TS TARGET TS TARGET :TS TARGET TS TARGET
------------------------------------------------------------------
00 FAS 16 CAS :00 FAS 16 CAS :00 FAS 16 CAS
01 NC 17 NC :01 V35 17 V35 :01 NC 17 NC
02 NC 18 NC :02 V35 18 V35 :02 NC 18 NC
03 NC 19 NC :03 V35 19 V35 :03 NC 19 NC
04 NC 20 P1M :04 V35 20 NC :04 NC 20 NC
05 NC 21 P2M :05 V35 21 NC :05 NC 21 NC
06 NC 22 P3M :06 V35 22 NC :06 NC 22 NC
07 NC 23 NC :07 V35 23 NC :07 NC 23 NC
08 NC 24 NC :08 V35 24 NC :08 NC 24 NC
09 NC 25 NC :09 V35 25 NC :09 NC 25 NC
10 NC 26 NC :10 V35 26 NC :10 NC 26 NC
11 NC 27 NC :11 V35 27 NC :11 NC 27 NC
12 NC 28 NC :12 V35 28 NC :12 NC 28 NC
13 NC 29 NC :13 V35 29 NC :13 NC 29 NC
14 NC 30 NC :14 V35 30 NC :14 NC 30 NC
15 NC 31 NC :15 V35 31 NC :15 NC 31 NC
------------------------------------------------------------------
PLEX2_01_CM>
<DEFAULT> command.
The <DEFAULT> command sets default configurations of the FlexGain Plex, V2
multiplexer.
Command syntax:
<DEFAULT> [1]
The <DEFAULT 1> sets the configuration similarly to the <SETDEFAULT>
command of the FG-Plex-xx device.
The values of the parameters set by the <DEFAULT> command are presented in the
Table below:
Table 15. Status of the configuration parameters after the <DEFAULT> command.
Parameter and the corresponding command Value
Clock source <SETCLOCK> INTERNAL
Modes of Е1 streams and CRC4 <PCMMODE> PCM30C
Cross-connect table <CONNECT>, <MUX> Empty
