FlexGain PLEX - Page 73

User’s manual FlexGain Plex, V2
Version 1.3 73 from 99
Real level -
10,
8
-9,8 -8,4 -7 -5,6 -4,2 -2,8 -1,4 0 +1,4 +2,8 +4,2 +5,6 +7,0 +8,4 +9,8
To display the help information, enter <PORT /H>
Example:
PLEX2_01_CM>PORT
Module signal ports configuration:
----------------------------------------------------------------------------
Port Type Signaling State PB RB PTS STS GainRX GainTX LEC NRT
----------------------------------------------------------------------------
P1 2EM TRANSPARENT LOCK C5 55 1,13 ---- 0.00db 0.00db No 10mv
P2 2EM MEGATERM LOCK C5 55 1,14 ---- 0.00db 0.00db No 10mv
P3 2EM MEGATERM LOCK C5 55 1,15 ---- 0.00db 0.00db No 10mv
P4 2EM MEGATERM LOCK C5 55 1,17 ---- 0.00db 0.00db No 10mv
P5 FXS MEGATERM LOCK C5 55 1,18 ---- 0.00db 0.00db No 10mv
P6 FXS MEGATERM LOCK C5 55 1,19 ---- 0.00db 0.00db No 10mv
P7 FXS MEGATERM LOCK C5 55 1,11 ---- 0.00db 0.00db No 10mv
P8 FXS MEGATERM LOCK C5 55 1,12 ---- 0.00db 0.00db No 10mv
----------------------------------------------------------------------------
PLEX2_01_CM>PORT ALL LEC OFF
PLEX2_01_CM>PORT P6 GAINRX 3
PLEX2_01_CM>PORT P1 NRT 33
<RESET> command.
This command resets the software. In this case, all saved configurations are
activated, while configurations which have not been saved are deleted. During the reset
process the device is disconnected from the console interface and the data transmission
over all interfaces is interrupted.
This command is used without any parameters.
To display the help information, enter <RESET /H>
Example:
PLEX2_01_CM>RESET
System will be restarted now.
<SAVE> command.
The <SAVE> command saves the configured parameters in the NONVRAM. This
command is used without any parameters.
To display the help information, enter <SAVE /H>
Example:
PLEX2_01_CM>SAVE
Saving module configuration.....................................................
..............................................................................
completed.
PLEX2_01_CM>
