User’s manual FlexGain Plex, V2
Version 1.3 74 from 99
<SIGBYTE> command.
The <SIGBYTE> command sets and maps the free-channel constants and the
replacement constant. The free-channel constant is a byte, which indicates the passive
signaling. The replacement constant is a byte, which replaces the free-channel constant
before its transmission to digital-to-analogue converter (codec).
Example:
SIGBYTE P1 54 55 sets the P1 port in the mode, in which constant 54 (hex) means
passive MEGATRANS signaling and is replaced by 55 (hex) before being transmitted to
the codec.
Command syntax:
<SIGBYTE> <Px|ALL PV RV>
where
Px is the number of the voice port (P1, P2 … P8). The value ALL applies the
<SIGBYTE> configuration to all voice ports.
PV is the free-channel constant.
RV is the replacement constant.
To display the help information, enter <SIGBYTE /H>
Example:
PLEX2_01_CM>SIGBYTE ALL 54 55
PLEX2_01_CM>SIGBYTE
--------------------------
MEGATRANS signaling values
--------------------------
Port PV RV
P1 54 55
P2 54 55
P3 54 55
P4 54 55
P5 54 55
P6 54 55
P7 54 55
P8 54 55
--------------------------
Note:
The recommended value of the second parameter is 55.
The <SIGBYTE> command without any parameters displays the constants of all
ports.
During operation of FlexGain Plex, V2 in the same communication network,
parameters PV and RV should coincide on all devices of the system.
