FLUXUS WW Installation
40 UMFLUXUS_WWV1-1EN, 2018-02-28
• Put the covers with the transducers on the rail.
• Correct the transducer distance, if necessary (see section 10.5.1 and 10.5.2).
• Tighten the screws of the cover (see Fig. 7.30).
Note! Make sure that the coupling foil remains on the contact surface of the transducers.
Fig. 7.30: Transducers with Variofix L on the pipe
