6 Mounting
PIOX R721 6.2 Sensor
31
UMPIOX_F72xV1-3EN, 2021-09-01
6.2.2.3 Installation of the sensor (chemistry design)
The sensor is installed into a standardized flange using the supplied process connection or directly flanged into a T-piece
as a long version.
6.2.2.4 Installation of the sensor (hygienic design)
The sensor can be connected to the standardized clamp flange connection Varivent type N or TriClamp 3".
Important!
After installing the sensor, check the tightness of the complete system with a compression test.
