13 Outputs
PIOX R721 13.1 Analog output
69
UMPIOX_F72xV1-3EN, 2021-09-01
Measuring range
The measuring range is defined.
• Enter the lowest expected measured value. The unit of measurement of the source item will be displayed.
Start of meas. range is the value assigned to the value Output MIN of the output range.
• Enter the highest expected measured value. The unit of measurement of the source item will be displayed.
End of meas. range is the value assigned to the value Output MAX of the output range.
Terminal assignment
The terminals for the connection of the output are displayed.
By pressing or further information is displayed.
• Press ENTER.
Output function test
The function of the output can now be tested.
• Connect an external measuring instrument to the terminals of the output.
• Select Yes to test the output. Select No to display the next menu item.
• Press ENTER.
• Enter a test value. It has to be within the output range.
• Press ENTER.
If the external measuring instrument displays the entered value, the output functions correctly.
• Select Repeat to repeat the test, Finish to display the next menu item.
• Press ENTER.
• Select Yes to test the assignment of the measured value to the output signal. Select No to display the next menu item.
• Press ENTER.
• Enter a test value for the selected physical quantity. It has to be within the output range.
• Press ENTER. If the external measuring instrument displays the entered value, the output functions correctly.
• Select Repeat to repeat the test. Select Finish to display the next menu item.
• Press ENTER.
Outputs\...\Start of meas. range
Outputs\...\End of meas. range
Outputs\...\Output info
Outputs\...\Test signal
Outputs\...\Enter test value
Outputs\...\Test mea. range
Outputs\...\Enter test value
