13 Outputs
13.2 Digital output PIOX R721
2021-09-01, UMPIOX_F72xV1-3EN
72
Assignment of a source item
Depending on the selected source item, status or event values can be output.
• Select the source item.
• Press ENTER.
13.2.2 Definition of the switching function for the status/event value
• Select the switching function for the output of the status/event value.
• Press ENTER.
If no measurement is carried out, all binary outputs are open (de-energized), independent of the set switching condition.
Terminal assignment
The terminals for the connection of the output are displayed.
By pressing or further information is displayed.
• Press ENTER.
Outputs\...\Source item
Tab. 13.4: Output of status values and event values
source item status value event value
physical quantities Refractometer x
Analysis x
Fluid properties x
Miscellaneous x
Refractive index x
events Event trigger x
Tab. 13.5: Selection of the switching condition
property switching function description
Status OK
(status value)
NC • valid measured value: binary output is closed
• invalid measured value: binary output is open
NO • valid measured value: binary output is open
• invalid measured value: binary output is closed
Idle state
(event value)
NO • event occurs: binary output is closed
• event has not occurred yet: binary output is open
NC • event occurs: binary output is open
• event has not occurred yet: binary output is closed
Outputs\...\Output info
