13 Outputs
PIOX R721 13.2 Digital output
73
UMPIOX_F72xV1-3EN, 2021-09-01
Output function test
The function of the output can now be tested.
• Connect a multimeter to the output.
• Select Yes to test the output. Select No to display the next menu item.
• Press ENTER.
• Select a list item as test value.
• Press ENTER.
• Select Repeat to repeat the test, Finish to display the next menu item.
• Press ENTER.
.
• Select Yes to test the status of the output signal. Select No to display the next menu item.
• Press ENTER.
• Select a list item as test value.
• Press ENTER.
Outputs\...\B1 Test signal
Outputs\...\B1 Enter test value
Tab. 13.6: Output function test – signal
list item description
NC • binary output is energized
• measured value has to be low ohmic
NO • binary output is de-energized
• measured value has to be high ohmic
Outputs\...\B1 Test mea. range
Outputs\...\B1 Enter test value
