Flexim PIOX R721 User Manual

13 Outputs
13.2 Digital output PIOX R721
2021-09-01, UMPIOX_F72xV1-3EN
74
• Select Repeat to repeat the test or Finish to display the next menu item.
• Press ENTER.
Tab. 13.7: Output function test – measuring range
list item switching function test value description
Status OK
(status value)
NC Status OK • binary output is energized
• measured value has to be low ohmic
Status error • binary output is de-energized
• measured value has to be high ohmic
NO Status OK • binary output is de-energized
• measured value has to be high ohmic
Status error • binary output is energized
• measured value has to be low ohmic
Idle state
(event value)
NC Passive • binary output is energized
• measured value has to be low ohmic
Active • binary output is de-energized
• measured value has to be high ohmic
NO Passive • binary output is de-energized
• measured value has to be high ohmic
Active • binary output is energized
• measured value has to be low ohmic
