Annex
A Menu structure PIOX R721
2021-09-01, UMPIOX_R721V1-3EN
98
Configuration of inputs
Inputs
Configure inputs
→ Temperature
→ Current
→ Voltage
→ Binary
Temperature
Tx Enable
No Yes
Pt100/Pt1000
Temperature offset [1]
No Yes
→ Temperature
Trigger value
No Yes
Function
→ Within range
→ Out of range
→ MAX (x>limit)
→ MIN (x<limit)
→ ERR (x=fail)
Range center Trigger value
Range width Hysteresis
Glitch interval
Input info
Test signal
Inputs
Legend
[3] only if enabled in the menu item Special functions > Dialogs/Menus
