Flexim PIOX R721 User Manual

Annex
PIOX R721 A Menu structure
99
UMPIOX_R721V1-3EN, 2021-09-01
Configuration of inputs
Inputs Current
Configure inputs Ix Enable
→ Temperature
→ Current
→ Voltage
→ Binary
No Yes
Source item
→ Temperature
→ Pressure
→ Density
→ Kin. viscosity
→ Dyn. viscosity
→ Sound speed
Customized Current
Input name
Unit of measurement
Decimal places
Input range
→ 0…20 mA
→ 4…20 mA
Other range
→ Input MIN I
→ Input MAX I
→ Start of meas. range
→ End of meas. range
Error value
Yes No
Trigger value
No Yes
Function
Input mode [1]
→ Within range
→ Out of range
→ MAX (x>limit)
→ MIN (x<limit)
→ ERR (x=fail)
Active Passive
Input info Range center Trigger value
Test signal Range width Hysteresis
Test mea. range
Glitch interval
Inputs
Legend
[1] only if supported by the hardware
