FLEX-6000 Signature Series – Maestro User Guide
Page 12
Copyright 2019 FlexRadio Systems. All Rights Reserved.
4.4.10 10-15 VDC Coaxial Power Connector
The power connector accepts a 2.1mm coaxial power plug to provide 10-15 VDC at 25W. Maestro is
supplied with an AC/DC power supply with a 12V output. Also included is a DC power cable with
2.1mm plug and pigtails on respective ends. This cable may be used to connect to the station power
supply bus.
4.4.11 USB Power Bank Connections
Maestro may be powered by a user supplied 5-volt battery placed in the battery compartment on
the back of the Maestro. This section details the installation steps:
The door to the battery compartment is located in the middle of the back panel of the Maestro.
