FLEX-6000 Signature Series – Maestro User Guide

Page 13

Depress the latch and open the battery compartment. Remove the door.

Insert a battery of suitable size. Secure the battery using the self-adhesive straps. The battery

must supply 5 volts DC and should be capable of supplying a minimum of 2.0 amps through a USB

type A connector.
