FLIR IP Series User Manual

Setup
5
• Zoom: Click + / - or use the slider to adjust the zoom level.
• Focus: Click + / - or use the slider to adjust the focus.
• Auto Focus: Click to have the camera automatically adjust the focus to the currently
selected zoom level.
Note
Adjustments in this menu are automatically saved.
5.1.4 Video
The Video tab allows you to configure the encoding settings for the camera. Video settings
are divided into Main Stream and Sub Stream.
To configure video quality settings:
1. Check Enable under Sub Stream to enable the sub stream or uncheck to disable.
#LX400038; r. 1.0/18537/18537; en-US
19

FLIR IP Series Specifications

General

Sensor Type	Uncooled microbolometer
Weather Resistance	Yes
Video Compression	H.264, MJPEG
Power	PoE (IEEE 802.3af)
Spectral Range	7.5 – 13 μm
Thermal Sensitivity	< 50 mK
Video Output	Ethernet
IP Rating	IP66
Resolution	320 × 240 pixels
Frame Rate	Up to 30 Hz (varies by model)
