FLIR IP Series User Manual

Live View
3
Upon login, the web interface opens to the Live View.
Note
Some functions are not available on all IP camera models, based on the features available.
1. Stream/Protocol Select: Allows you to select the video stream and protocol used in
Live View.
• Main Stream: Click to view the Main Stream. The Main Stream provides better pic-
ture quality and resolution, but requires higher bandwidth.
• Sub Stream: Click to view the Sub Stream. The Sub Stream is recommended for
better performance when viewing the camera over the Internet.
• Protocol: Select the protocol that will be used to stream video: TCP or UDP.
Note
Multicast is not supported.
#LX400038; r. 1.0/18537/18537; en-US
5

FLIR IP Series Specifications

General

Sensor Type	Uncooled microbolometer
Weather Resistance	Yes
Video Compression	H.264, MJPEG
Power	PoE (IEEE 802.3af)
Spectral Range	7.5 – 13 μm
Thermal Sensitivity	< 50 mK
Video Output	Ethernet
IP Rating	IP66
Resolution	320 × 240 pixels
Frame Rate	Up to 30 Hz (varies by model)
