FLIR IP Series User Manual

Firmware Upgrade Tool6
9. Click Upgrade. Wait for the upgrade to complete. Do not power off the system or
disconnect the power cable during upgrade. The system will restart when the up-
grade is complete.
9.1. Click System Upgrade
9.2. Click Open and select the firmware file
9.3. Click Upgrade
#LX400038; r. 1.0/18537/18537; en-US
57

FLIR IP Series Specifications

General

Sensor Type	Uncooled microbolometer
Weather Resistance	Yes
Video Compression	H.264, MJPEG
Power	PoE (IEEE 802.3af)
Spectral Range	7.5 – 13 μm
Thermal Sensitivity	< 50 mK
Video Output	Ethernet
IP Rating	IP66
Resolution	320 × 240 pixels
Frame Rate	Up to 30 Hz (varies by model)
