Figure 5.2 Explanations of callouts
Description of partPart No.Callout
Protective plastic window194 5601
Protective window1 194 9772
124 mm IR lens194 5793
72 mm IR lens194 1764
18 mm IR lens194 4015
9.0 mm IR lens194 7026
64/150 close-up IR lens194 5337
34/80 close-up IR lens1 194 9788
50 μm IR lens1 700 5009
Battery1 195 26810
2-bay battery charger1 195 26711
External power supply1 909 52812
Automotive (cigarette lighter) 12 VDC adapter1 195 14313
Shoulder strap117 13214
Adapter for CompactFlash™ card1 909 82015
CompactFlash™ card1 909 65316
■
Protective cap for RS-232/USB connector
■
Protective cap for unused remote control con-
nector
1 910 23317
Protective cap for unused headset connector1 910 23218
USB cable1 195 31419
RS-232 cable1 195 31320
CVBS cable (composite video cable)1 909 77522
5
14 Publ. No. 1557978 Rev. a155 – ENGLISH (EN) – February 6, 2006
