FLIR ThermaCam P25 - Rear Connectors

6.2 Rear connectors
10593503;a1
Figure 6.3 How to connect system components: Rear connectors
Figure 6.4 Explanations of callouts
ExplanationCallout
CompactFlash card1
Power supply cable2
CVBS cable (i.e. composite video)3
Remote control cable4
6
16 Publ. No. 1557978 Rev. a155 – ENGLISH (EN) – February 6, 2006
6 – Connecting system components
