CommentsValueLabel
Move the joystick left/right to enable or disable
noise reduction.
When Noise reduction is set to On, the image
noise decreases and the image appears more
stable.
However, when the camera or the object moves,
and Noise reduction set to On, this may create
some image smearing.
■
On
■
Off
Noise reduction
Press the Adjust region button to display a region
on the screen that will be used when autoadjusting
the camera.
Adjust region
10.2.5.2 Save
10568203;a2
Figure 10.24 Save Setup dialog box
Figure 10.25 Explanations of the Save Setup dialog box
CommentsValueLabel
For a detailed explanation, see below.
■
Unique counter
■
Date
■
Directory
Image naming
■
If On is selected, all on-screen graphics will be
saved together with the image
■
If Off is selected, only the image (together with
any temperature information) will be saved
➲ The difference between images saved with or
without on-screen graphics will only be evident
when looking at the images using a third-party
image viewer.
■
On
■
Off
Overlay
Figure 10.26 Naming based on unique counter – explanations
Typical syntax: IR_nnnn.jpg
■
IR = infrared imageIR
Unique counternnnn
IR_0003.jpgExample
10
78 Publ. No. 1557978 Rev. a155 – ENGLISH (EN) – February 6, 2006
10 – Camera program
