6 Connecting system components
6.1 Front connectors
10438803;a2
Figure 6.1 How to connect system components: Front connectors
Figure 6.2 Explanations of callouts
ExplanationCallout
USB or RS-232 cable.1
Not implemented.2
6
Publ. No. 1557978 Rev. a155 – ENGLISH (EN) – February 6, 2006 15
