CommentsValueLabel
You can set the Emissivity if Local is enabled. If
not, this option will be shaded.
➲ If you enter an emissivity value less than 0.30
the emissivity box will begin flashing to remind you
that this value is unusually low.
User-defined
(0.01–1.00)
Emissivity
You can set T Reflected if Local is enabled. If not,
this option will be shaded.
User-definedT Reflected
You can set Distance if Local is enabled. If not,
this option will be shaded.
User-definedDistance
10.2.3.3 Add isotherm
The isotherm command colors all pixels with a temperature above, below or between
one or more preset temperature levels.
10390903;a2
Figure 10.12 Temperature scale showing an isotherm set to above +62 °C
Point to Add isotherm and press the joystick to add an isotherm. An isotherm has
now be added to your image. Press and hold down the joystick for one second when
the isotherm (in the temperature scale) is selected to display a shortcut menu.
10
Publ. No. 1557978 Rev. a155 – ENGLISH (EN) – February 6, 2006 71
10 – Camera program
