Fluke 1750 Getting Started Guide

1750
Getting Started Guide
10
a. Use Windows Explorer to locate the sw/FPV_Vx.yy.exe file on the
CD. Replace x.yy with the current version number shipped on the CD.
b. Double-click FPV_Vx.yy_Install.exe to launch the installation
program.
5. Select a language preference for the installation.
6. Follow the on-screen prompts. Power View is installed in the Programs
folder on the PDA.
7. To start Power View, select Start, and then Programs on the PDA.
8. Tap the Power View icon (
) to start using the application.
Language Selection
Power View features a localized user interface for English, German, French,
Spanish, Chinese, and Italian. When Power View operates for the first time on
a new PDA or after a hard reset, it directly opens the language setup window.
This window is also accessed by Menu>1750 Setup>Language.
The Language window also provides the option to choose between the phase
identifiers A, B, C and L1, L2, L3.

Fluke 1750 Specifications

General

Type	Power Quality Analyzer
Frequency Measurement Range	42.5 Hz to 69 Hz
Safety Rating	CAT IV 600 V, CAT III 1000 V
Accuracy	±0.1% of reading
Harmonics	Up to 50th harmonic
Communication	Ethernet, USB
Power Supply	100 V to 240 V AC
Channels	4 voltage, 4 current
Battery Backup	Yes, internal battery
Measurement Parameters	Voltage, Current, Power, Harmonics, Flicker
Data Logging Interval	1 second to 60 minutes
Battery Life	45 minutes (UPS)
Voltage Measurement Range	1 to 1000 V (phase to neutral)
Operating Temperature	-10 to 50 °C
