Fluke 1750 Getting Started Guide

1750
Getting Started Guide
46
Auto Report
The Auto Report function automatically generates a report from the active
measurement database. The Auto Report function is started by selecting Auto
Report from the file menu.
Report Configuration
The items for reporting relate to the items that are usually viewed in the main
software package:
• Summary
• Volts/Amps/Hz
• Events
• Harmonics – Bar graphs and Time plots
• THD
• Flicker
• Power/Energy
In addition, there are Common Settings. The Common Settings are used to:
• Define the start and end dates and times of the report.
• Select the types of graphs that are reported; a graph of the entire data
set may be reported or this can be split into hourly, daily, or weekly
sections for high-resolution data.
• Save and Load defined reports – default templates are provided which
may be loaded.
• Select Output Format – The Auto Report is a PDF (ready-to-print
format) or RTF (rich text format) file that can be edited by the user
before printing.
The standard report configuration files, Basic Report.ini, Intermediate
Report.ini, and Comprehensive Report.ini templates can be loaded or the user
can select each individual item for the report. Alternatively, an existing report
configuration can be opened, edited, and saved with a new name (the default
report configurations are set to read-only to prevent changes being saved).

Fluke 1750 Specifications

General

Type	Power Quality Analyzer
Frequency Measurement Range	42.5 Hz to 69 Hz
Safety Rating	CAT IV 600 V, CAT III 1000 V
Accuracy	±0.1% of reading
Harmonics	Up to 50th harmonic
Communication	Ethernet, USB
Power Supply	100 V to 240 V AC
Channels	4 voltage, 4 current
Battery Backup	Yes, internal battery
Measurement Parameters	Voltage, Current, Power, Harmonics, Flicker
Data Logging Interval	1 second to 60 minutes
Battery Life	45 minutes (UPS)
Voltage Measurement Range	1 to 1000 V (phase to neutral)
Operating Temperature	-10 to 50 °C
